LiPo

11.1V LiPo Battery 11000mAh 9553160-3S for RC Drone Battery, UAV Battery Pack, RC Airplane Battery

Parameter	Specification
Model	VTC-LP9553160-3S1P
Voltage	11.1V
Capacity	11000mAh
Max Size (Thickness x Width x Length)	9.7X53.5X162mm
Operating Temperature	-20℃ to 60℃
Standard Charge Rate	0.5C
Standard Discharge Rate	1C
Configuration	3S1P
Weight	585g

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotationDatasheet unavailable

Product overview

11.1v 11000mah 9553160-3s lithium ion polymer battery factory in China | Battery Manufacturers in China & Battery Supply Factory

VTCBATT is an 11.1V LiPo battery manufacturer and factory focused on 9553160-3S 11000mAh rechargeable battery production, custom pack design, and application-ready integration. For B2B customers, VTCBATT supports cell matching, PCM/BMS protection, connector selection, wire length, discharge current design, labeling, and batch consistency for RC drones, UAV battery packs, RC airplanes, RC cars, robotics, electric sprayers, portable lighting, and fish finders.

01

Long Cycle Life

Based on 0.5C/1C cycling, the VTCBATT 11.1v 11000mah 9553160-3s lipo battery can maintain over 80% capacity after 500 cycles and totally reach 1000 times cycle life.

02

Temperature Performance

VTCBATT 11.1v 11000mah 9553160-3s Lipo battery can be discharged from -20℃ to 60℃.
This wide temperature range performance enables the battery to operate in many conditions.

03

Different Discharge Rate

VTCBATT 11.1v 11000mah 9553160-3s lipo battery can be discharged in different rates of 0.2C,0.5C,1C,2C,3C to meet different power consumption.

04

Strict Cell Match

Strict cell match standards in 10mV voltage tolerance, 5mAh capacity tolerance, and 1mΩ to ensure excellent performance of the total 11.1v 11000mah 9553160-3s lipo battery pack.Furthermore,the PCB with cell balance function can long-lasting power supply without any failure.

05

PCB with NTC

VTCBATT 11.1v 11000mah 9553160-3s lipo batteries are provided with NTC(Negative Temperature Coefficient), a kind of temperature sense to decrease the resistance as the temperature increases, allowing accurate temperature monitoring of the batteries. The NTC plays a critical role in improving the battery reliability and safety.

Technical insight

Product and application details

Electric Sprayer Battery

The 11000mAh capacity sustains long spraying sessions without frequent recharging interruptions.

Fish Finder Battery

Operating down to -20℃ ensures reliable performance during cold water fishing expeditions.

Portable Lighting Battery

Weighing only 585g, this unit adds minimal load to handheld lighting gear.

RC Airplane Battery

Its 53.5mm width fits narrow fuselage compartments while delivering stable 11.1V thrust.

RC Car Battery

The compact 9.7mm thickness allows secure mounting in tight chassis battery trays.

RC Drone Battery

Three-cell configuration provides the precise voltage required for consistent motor RPM control.

Robotics Battery

High capacity supports extended autonomous operation for complex robotic movement algorithms.

UAV Battery Pack

162mm length aligns with standard airframe designs for balanced center-of-gravity placement.

VTCBATT is an 11.1V LiPo battery manufacturer and factory focused on 9553160-3S 11000mAh rechargeable battery production, custom pack design, and application-ready integration. For B2B customers, VTCBATT supports cell matching, PCM/BMS protection, connector selection, wire length, discharge current design, labeling, and batch consistency for RC drones, UAV battery packs, RC airplanes, RC cars, robotics, electric sprayers, portable lighting, and fish finders.

Factory capability

VTCBATT Production and Service

VTCBATT not only focuses on customized design and excellent service to meet the diverse demands of different customers, but also devotes itself to precise and standardized manufacturing in every process to ensure the highest-quality batteries. Meanwhile, VTCBATT provides comprehensive support from pre-sales to after-sales, focusing on customer feedback to establish long-term and win-win cooperation. VTCBATT professional sales and technical engineer teams will be your custom battery experts for reliable and responsive project support.

▶

Modern Manufacturing

From raw materials mixing to cell testing, VTCBATT adopts automated manufacturing processes to improve production efficiency and battery quality, safety, and reliability. The manufacturing process is monitored and tested before material moves to the next procedure.

▶

Trusted by Global Customers

Over the past 20 years, VTCBATT has built partnerships with customers in more than 50 countries. Reliable quality, responsive service, and tailored battery solutions support long-term cooperation with equipment manufacturers, distributors, and brands.
