LiFePO4

Ultra long cycle life and lightweight Lifepo4 24V 4.5Ah battery for LED Light Panels, Portable PA Systems, solar-powered security cameras

Parameter	Specification
Nominal Voltage	25.6V
Capacity	4.5Ah
Energy	115.2Wh
Discharge Cut-off Voltage	16V
Max Charge Current	4.5A
Max Discharge Current	4.5A
Cycle Life	>3000
Self-discharge Rate	<2% per Month
Dimensions	190 x 70 x 74mm
Weight	1.25Kg
Operating Temperature	-20C to 60C
Storage Temperature	0C to 25C
Protection	Overcharge, Overdischarge, Overcurrent / Short-Circuit, Temperature, Cell Balancing

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotation View More Datasheet

Product overview

Ultra long cycle life and lightweight Lifepo4 24V 4.5Ah battery for LED Light Panels, Portable PA Systems, solar-powered security cameras | Battery Manufacturers in China & Battery Supply Factory

VTCBATT manufactures LiFePO4 24V 4.5Ah batteries with stable output and long cycle life for portable lighting systems, mobile audio equipment and solar security camera applications

01

LiFePO4 Battery Advantage

Ultra-Long Lifecycle: Over 3,000 deep cycles, lasting 10 times longer than traditional lead-acid batteries.
Lightweight: Typically uses the standard SLA case size, but 1/3 weight of the traditional 24V 4.5Ah lead acid battery.Drop-in replacement for alarm system and UPS units.
Cost Per Cycle: Lifepo4 battery is only 1/4 cost of traditional lead acid battery in long run term.
100% Usable Capacity： Supports 100% DOD, delivering 40% more usable energy than equivalent lead-acid packs
Smart BMS Protection： Integrated Smart BMS prevents overcharging and shorts, ensuring absolute safety for users.
Eco-Friendly & Compliant ： Non-toxic, sustainable, and fully certified with CE, UN38.3, and RoHS standards.

Technical insight

Product and application details

floor sweepers scrubbers

The 24V nominal voltage provides the necessary torque for heavy-duty scrubber motors while the compact 4.5Ah capacity keeps the unit lightweight.

industrial tow tractors

This 24V LiFePO4 pack delivers consistent voltage under load, ensuring reliable traction for industrial tow tractors during extended shifts.

robotic AGVs

Lightweight design reduces overall AGV payload weight, enhancing maneuverability and energy efficiency for autonomous guided vehicles in tight spaces.

RV(creational vehicle)

The 4.5Ah capacity offers sufficient power for auxiliary systems in compact RVs, while the lightweight build preserves precious cargo space.

variable message boards

Stable 24V output ensures clear LED illumination for variable message boards, even when powered by limited solar energy storage.

Application

Ultra-long cycle life minimizes downtime for critical portable PA systems, ensuring uninterrupted audio performance during prolonged outdoor events.

Application

Ultra-long cycle life minimizes downtime for critical portable PA systems, ensuring uninterrupted audio performance during prolonged outdoor events.

Application

Ultra-long cycle life minimizes downtime for critical portable PA systems, ensuring uninterrupted audio performance during prolonged outdoor events.
