LiFePO4

Ultra long cycle life and lightweight Lifepo4 24V 5Ah battery for portable power stations, solar street lighting, remote cabin power

Parameter	Specification
Nominal Voltage	25.6V
Capacity	5Ah
Energy	128Wh
Discharge Cut-off Voltage	16V
Max Charge Current	5A
Max Discharge Current	5A
Cycle Life	>3000
Self-discharge Rate	<2% per Month
Dimensions	190 x 70 x 74mm
Weight	1.2Kg
Operating Temperature	-20℃ to 60℃
Storage Temperature	0℃ to 25℃
Protection	Overcharge, Overdischarge, Overcurrent / Short-Circuit, Temperature, Cell Balancing

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotation View More Datasheet

Product overview

Ultra long cycle life and lightweight Lifepo4 24V 5Ah battery for portable power stations, solar street lighting, remote cabin power | Battery Manufacturers in China & Battery Supply Factory

VTCBATT manufactures LiFePO4 24V 5Ah batteries with stable output and long cycle life for portable energy storage, solar lighting systems and off-grid cabin power applications.

01

LiFePO4 Battery Advantage

Ultra-Long Lifecycle: Over 3,000 deep cycles, lasting 10 times longer than traditional lead-acid batteries.
Lightweight: Typically uses the standard SLA case size, but 1/3 weight of the traditional 24V 5Ah lead acid battery.Drop-in replacement for alarm system and UPS units.
Cost Per Cycle: Lifepo4 battery is only 1/4 cost of traditional lead acid battery in long run term.
100% Usable Capacity： Supports 100% DOD, delivering 40% more usable energy than equivalent lead-acid packs
Smart BMS Protection： Integrated Smart BMS prevents overcharging and shorts, ensuring absolute safety for users.
Eco-Friendly & Compliant ： Non-toxic, sustainable, and fully certified with CE, UN38.3, and RoHS standards.

Technical insight

Product and application details

portable power stations

Its lightweight design ensures easy portability without sacrificing the stable 24V output needed for consistent energy delivery.

industrial tow tractors

The ultra-long cycle life withstands the rigorous daily discharge patterns required by heavy-duty industrial towing operations.

RV(creational vehicle)

Lightweight construction reduces overall vehicle weight, improving fuel efficiency while providing reliable 24V power for onboard systems.

variable message boards

The compact 5Ah capacity fits tight mounting spaces while delivering the necessary 24V for clear digital signage.

Portable PA Systems

Lightweight form factor allows for easy transport during events while the 24V voltage supports high-power audio amplifiers.

solar-powered security cameras

Long cycle life ensures years of reliable operation for continuous monitoring duties in remote outdoor security setups.

remote cabin power

Ultra-long cycle life provides durable, maintenance-free energy storage for essential loads in off-grid living environments.

solar street lighting

The 24V configuration directly matches standard solar street light controllers, ensuring efficient charging and discharge cycles.
