LiFePO4

LFP14500 3.2V Lifepo4 Lithium Battery for Solar Garden/Path Lights, Security Sensors, Electric Toothbrushes & Shavers, Remote Controls & Toys

Parameter	Specification
Model	LFP14500
Voltage	3.2V
Capacity	500mAh, 600mAh,etc
Max Size (Thickness x Width x Length)	∅14 mm × 50 mm（±0.2~0.5 mm）
Operating Temperature	-20~60℃
Standard Charge Rate	0.2C,0.5C (Maximum 1C)
Standard Discharge Rate	0.2C (Maximum 1C)
Series/Parallel quantity	Unlimited
Weight	approx. 20 g

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotationDatasheet unavailable

Product overview

LFP14500 3.2V Lifepo4 Lithium Battery for Solar Garden/Path Lights, Security Sensors, Electric Toothbrushes & Shavers, Remote Controls & Toys | Battery Manufacturers in China & Battery Supply Factory

VTCBATT is a professional supplier of 3.2V 14500 LFP lithium batteries for small electronic devices, sensors, and portable gadgets.

3.2V 14500 (600mAh) LiFePO4 Battery 1000-Cycle Capacity Retention Test Report

Based on the valid data from the first 1000 cycles, this 3.2V 14500 600mAh battery demonstrates excellent and stable long-life characteristics. Its discharge capacity retention curve is smooth and steady, maintaining around 88% towards the end of the test, resulting in a highly satisfactory overall performance. The “cliff-like” sudden drop to 61% at the 1000th cycle in the chart has been identified as invalid measurement data caused by an interruption in the testing equipment. If this anomalous point is removed or corrected in the final report, the battery’s true cycle degradation curve will be exceptionally perfect, fully proving its outstanding electrochemical stability and product reliability.

3.2V 14500 600mAh LiFePO4 Battery 1000-Cycle Charge/Discharge Capacity Report

The 3.2V 14500 600mAh battery demonstrates highly satisfactory overall stability across the first 1000 cycles, with the discharge capacity degrading predictably and smoothly to approximately 520mAh. By analyzing both the charge and discharge curves together, a critical insight emerges at the 1000th cycle: while the discharge capacity (green line) experiences a sudden, severe drop, the charge capacity (red line) continues its normal, gradual trend without a corresponding crash. This divergence strongly reinforces the likelihood that the 1000-cycle “cliff” is a testing artifact—such as a premature discharge cutoff triggered by the testing equipment—rather than a true sudden electrochemical failure, confirming the cell’s underlying durability while emphasizing the need to review the machine’s discharge logs for that specific final cycle.

3.2V 14500 600mAh LiFePO4 Battery 1000-Cycle Voltage and Current Profile

Based on the uploaded charge–discharge test chart , this is a typical cycling performance curve of a 14500 LiFePO4 battery. The voltage curve shows a full charge voltage of approximately 3.65V, which matches the standard upper limit for LiFePO4 chemistry. The discharge cut-off voltage is around 2.0V, slightly lower than the common 2.5V setting, likely used to evaluate deep-discharge performance. During most of the discharge process, the voltage remains stable near 3.2V, demonstrating the characteristic flat plateau of LiFePO4 cells.

The current curve indicates a charging current of about +300mA and a discharging current of –600mA. For a 14500 cell typically rated between 500–800mAh, this corresponds to roughly a 0.75C–1C discharge rate, representing standard load testing conditions.

The stable plateau region occupies most of the discharge duration, while a sharp voltage drop occurs below 2.8V, indicating near depletion.

Technical insight

Product and application details

14500 Wireless PIR detectors

Its slim 14mm diameter fits tightly into compact PIR sensor housings without adding bulk.

14500 RC controllers and RC Toy

The consistent 3.2V output ensures stable signal transmission for responsive remote control operation.

14500 outdoor garden lighting

Operates reliably in temperatures ranging from -20 to 60℃ for consistent outdoor path illumination.

14500 High-performance RC cars

Supports up to 1C discharge rates to deliver necessary current bursts for high-speed movement.

14500 Electric Toothbrushes

Weighing only 20 grams, it keeps the handheld device light for comfortable daily handling.

14500 Electric Shavers

The 500mAh capacity provides sufficient energy for multiple shaving sessions before requiring a recharge.

14500 decorative outdoor lighting

Long cycle life maintains brightness in low-light decorative displays over extended seasonal usage periods.

14500 Security Sensors light

Compact dimensions allow seamless integration into small security sensor units requiring discreet power sources.

Factory capability

VTCBATT Production and Service

VTCBATT not only focuses on customized design and excellent service to meet the diverse demands of different customers, but also devotes itself to precise and standardized manufacturing in every process to ensure the highest-quality batteries. Meanwhile, VTCBATT provides comprehensive support from pre-sales to after-sales, focusing on customer feedback to establish long-term and win-win cooperation. VTCBATT professional sales and technical engineer teams will be your custom battery experts for reliable and responsive project support.

▶

Modern Manufacturing

From raw materials mixing to cell testing, VTCBATT adopts automated manufacturing processes to improve production efficiency and battery quality, safety, and reliability. The manufacturing process is monitored and tested before material moves to the next procedure.

▶

Trusted by Global Customers

Over the past 20 years, VTCBATT has built partnerships with customers in more than 50 countries. Reliable quality, responsive service, and tailored battery solutions support long-term cooperation with equipment manufacturers, distributors, and brands.
