LiPo

Custom 3S 11.1V 8000mAh LiPo battery pack for high-capacity portable power, compact equipment, robotics, and RC applications

Parameter	Specification
Model	VTC-LP8860102-3S1P
Voltage	11.1V
Capacity	8000mAh
Max Size (Thickness x Width x Length)	27.5X60.5X104mm
Operating Temperature	-20℃ to 60℃
Standard Charge Rate	0.5C
Standard Discharge Rate	1C
Configuration	3S1P
Weight	424.5g

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotationDatasheet unavailable

Product overview

3S 8860102 11.1V 8000mAh lithium ion polymer battery factory in China | Battery Manufacturers in China & Battery Supply Factory

This high-capacity 11.1V 8000mAh LiPo battery features a 3S configuration with built-in BMS protection and customizable connectors including JST, Molex, and Hirose. Designed for portable electronics, robotics, communication devices, and industrial equipment, it delivers stable output, low internal resistance, and long cycle life. The BMS ensures overcharge, over-discharge, overcurrent, short-circuit, and temperature protection, providing safe and reliable performance in diverse applications.

01

Long Cycle Life

Based on 0.5C/1C cycling, the VTCBATT 3S 8860102 11.1V 8000mAh lipo battery can maintain over 80% capacity after 500 cycles and totally reach 1000 times cycle life.

02

Low Self Discharge Rate

After 30-day and 60-day storage, there is slight 1%-2% slight voltage decrease under 50% SOC at 25°C.

03

Customization

VTCBATT can support full customization of the 3S 8860102 11.1V 8000mAh lipo batteries in different sizes, capacities, connectors, discharge rates, and cases. Just inform us of your specific requirement, and our professional engineers can provide you with the customized lipo battery proposal.

04

PCB with NTC

VTCBATT 3S 8860102 11.1V 8000mAh lipo batteries are provided with NTC(Negative Temperature Coefficient), a kind of temperature sense to decrease the resistance as the temperature increases, allowing accurate temperature monitoring of the batteries. The NTC plays a critical role in improving the battery reliability and safety.

Technical insight

Product and application details

Communication devices

The compact 27.5mm thickness ensures the pack fits snugly inside portable communication gear without adding excessive bulk.

Emergency lighting

A wide -20℃ to 60℃ operating range guarantees consistent performance for emergency lighting units in extreme environmental conditions.

Portable monitors

Weighing only 424.5g, this lightweight pack minimizes overall load for handheld portable monitors used in field operations.

RC boats

The 11.1V 3S1P configuration delivers stable voltage output essential for maintaining consistent propulsion in RC boat motors.

RC cars

With an 8000mAh capacity, this high-capacity pack provides extended runtime for RC cars during competitive racing events.

Robotics

Standard 1C discharge capability supports the steady power draw of robotic actuators without risking thermal instability.

Surveying instruments

The precise 11.1V nominal voltage aligns directly with the power input requirements of professional surveying instruments.

UAVs and drones

Dimensions of 104x60.5mm allow for flexible integration into custom UAV frames where space is severely limited.

This high-capacity 11.1V 8000mAh LiPo battery features a 3S configuration with built-in BMS protection and customizable connectors including JST, Molex, and Hirose. Designed for portable electronics, robotics, communication devices, and industrial equipment, it delivers stable output, low internal resistance, and long cycle life. The BMS ensures overcharge, over-discharge, overcurrent, short-circuit, and temperature protection, providing safe and reliable performance in diverse applications.

Factory capability

VTCBATT Production and Service

VTCBATT not only focuses on customized design and excellent service to meet the diverse demands of different customers, but also devotes itself to precise and standardized manufacturing in every process to ensure the highest-quality batteries. Meanwhile, VTCBATT provides comprehensive support from pre-sales to after-sales, focusing on customer feedback to establish long-term and win-win cooperation. VTCBATT professional sales and technical engineer teams will be your custom battery experts for reliable and responsive project support.

▶

Modern Manufacturing

From raw materials mixing to cell testing, VTCBATT adopts automated manufacturing processes to improve production efficiency and battery quality, safety, and reliability. The manufacturing process is monitored and tested before material moves to the next procedure.

▶

Trusted by Global Customers

Over the past 20 years, VTCBATT has built partnerships with customers in more than 50 countries. Reliable quality, responsive service, and tailored battery solutions support long-term cooperation with equipment manufacturers, distributors, and brands.
