Technical insight
Product and application details
Drone
The compact 8.2mm thickness enables sleek aerodynamic designs for UAVs requiring low profile power sources.
GPS Tracker
A 101g weight minimizes drag on portable tracking units while delivering sustained 3.7V output.
IOT Devices
Operational stability from -20℃ to 60℃ ensures reliable data transmission in harsh environmental conditions.
Medical Devices
The 5000mAh capacity supports extended usage periods for portable diagnostic tools during critical procedures.
Portable Equipment
Dimensions of 125mm x 45.5mm x 8.2mm allow seamless integration into slim handheld electronic casings.
Robotics
A 1C discharge rate provides steady current flow for precise motor control in small robots.
Solar Sensor
Standard 0.5C charging rate protects cell longevity when integrated with variable solar energy inputs.
UAV
The 1S1P configuration offers a simple, lightweight power solution for compact unmanned aerial vehicles.
LP8045123 5000mah Material Safety Data Sheet Report No.: 18380BC20263018 1. Chemical Product and Company Identification Product Name: Lithium Polymer Battery Sample Model: LP8045123 Rating: Nominal Voltage: 3.7V; Rated Capacity: 5000mAh, 18.5Wh Weight: 57.5g Manufacturer: VTC POWER CO., LTD Address: 1205C, Block 1C, Hengming One, Aixin Road, Longgang Center, Shenzhen, China Telephone: 0086-0755-33065435 2. Composition/Information on Ingredients Chemical Name Percent of Content CAS No. Lithium Cobalt Dioxide (LiCoO2) 25%~35% 12190-79-3 Graphite (C) 15%~20% 7782-42-5 Poly Vinylidene Fluoride (PVDF) 1%~5% 24937-79-9 Acetylene Black (SP) 0.5%~3% 1333-86-4 Aluminum (AL) 21%~23% 7429-90-5 Copper (Cu) 10%~11% 7440-50-8 Lithium Hexafluorophosphate (LiPF6) 10%~15% 21324-40-3 3. Hazards Summarizing
1. Chemical Product and Company Identification
| Product Name: | Lithium Polymer Battery |
| Sample Model: | LP8045123 |
| Rating: | Nominal Voltage: 3.7V; Rated Capacity: 5000mAh, 18.5Wh |
| Weight: | 57.5g |
| Manufacturer: | VTC POWER CO., LTD |
| Address: | 1205C, Block 1C, Hengming One, Aixin Road, Longgang Center, Shenzhen, China |
| Telephone: | 0086-0755-33065435 |
2. Composition/Information on Ingredients
| Chemical Name | Percent of Content | CAS No. |
|---|---|---|
| Lithium Cobalt Dioxide (LiCoO2) | 25%~35% | 12190-79-3 |
| Graphite (C) | 15%~20% | 7782-42-5 |
| Poly Vinylidene Fluoride (PVDF) | 1%~5% | 24937-79-9 |
| Acetylene Black (SP) | 0.5%~3% | 1333-86-4 |
| Aluminum (AL) | 21%~23% | 7429-90-5 |
| Copper (Cu) | 10%~11% | 7440-50-8 |
| Lithium Hexafluorophosphate (LiPF6) | 10%~15% | 21324-40-3 |
3. Hazards Summarizing
Danger sort: N/A
Routes of entry: Leaking electrolyte can irritate eyes and skin. Inhalation of fumes from heated or leaking batteries can cause respiratory irritation. Ingestion is harmful and can cause chemical burns.
Health harm: Exposure to electrolyte can cause burns, respiratory distress, and tissue damage to the throat/gastrointestinal track.
4. First Aid Measures
- Skin contact: Flush with copious amounts of water for at least 15 minutes.
- Eye contact: Flush with water for 15 minutes and seek medical attention immediately.
- Inhalation: Remove to fresh air. If irritation persists, consult a physician.
- Ingestion: Rinse mouth with water; consult a physician immediately.
5. Fire Fighting Measures
Extinguishing Media: Dry chemical type extinguishers are most effective; CO2 also works effectively.
Special Hazards: Battery may explode or leak hazardous vapors if exposed to excessive heat, fire, or over-charge.
6. Handling and Storage
Handling: Use dedicated chargers. Do not disassemble, crush, or immerse in water. Avoid short circuits.
Storage: Store in a cool (20°C±5°C), dry, and ventilated area. Keep away from heating equipment and direct sunlight.
7. Transport Information
| UN Number: | 3480 & 3481 |
| Proper Shipping Name: | Lithium Ion Batteries |
| Packing Instruction: | 965 II/IB, 966 II, 967 II |
| Marine Pollutant: | No |
