LiFePO4

Ultra long cycle life and lightweight Lifepo4 12V 120Ah battery for RV(creational vehicle), robotic AGVs, industrial tow tractors

Parameter	Specification
Nominal Voltage	12.8V
Capacity	120Ah
Energy	1280Wh
Discharge Cut-off Voltage	8V
Max Charge Current	100A
Max Discharge Current	200A(≤5s)
Cycle Life	>3000
Self-discharge Rate	2%
Dimensions	305 x 169 x 210mm
Weight	12Kg
Operating Temperature	-20℃ to 60℃
Storage Temperature	0 to 25ºC
Protection	Overcharge, Overdischarge, Overcurrent / Short-Circuit, Temperature, Cell Balancing

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotation View More Datasheet

Product overview

Ultra long cycle life and lightweight Lifepo4 12V 120Ah battery for RV(creational vehicle), robotic AGVs, industrial tow tractors | Battery Manufacturers in China & Battery Supply Factory

VTCBATT manufactures LiFePO4 12V 120Ah batteries featuring long cycle life and stable performance for RV power systems, AGVs and industrial tow tractor applications.

01

LiFePO4 Battery Advantage

Ultra-Long Lifecycle: Over 3,000 deep cycles, lasting 10 times longer than traditional lead-acid batteries.
Lightweight: Typically uses the standard SLA case size, but 1/3 weight of the traditional 12V 120Ah lead acid battery.Drop-in replacement for alarm system and UPS units.
Cost Per Cycle: Lifepo4 battery is only 1/4 cost of traditional lead acid battery in long run term.
100% Usable Capacity： Supports 100% DOD, delivering 40% more usable energy than equivalent lead-acid packs
Smart BMS Protection： Integrated Smart BMS prevents overcharging and shorts, ensuring absolute safety for users.
Eco-Friendly & Compliant ： Non-toxic, sustainable, and fully certified with CE, UN38.3, and RoHS standards.

Technical insight

Product and application details

Solar System

The 120Ah capacity ensures extended energy storage for off-grid solar setups requiring sustained daily discharge cycles.

Marine & Boating

Lightweight construction reduces vessel weight while the 12V output powers onboard electronics without compromising stability.

Motorcycles

Compact 12V form factor fits tight engine bays, offering reliable ignition power for motorcycles needing lightweight solutions.

RV(creational vehicle)

Ultra-long cycle life supports frequent deep discharges from RV appliances, ensuring durability over many travel seasons.

Emergency Power Backup & UPS

Stable 12V output maintains critical system uptime during grid outages, providing dependable backup for essential equipment.

Robotic AGVs

Lightweight design minimizes overall robot mass, allowing AGVs to maximize payload capacity while navigating factory floors.

Industrial tow tractors

High cycle life withstands rigorous daily charging patterns, sustaining performance for heavy-duty industrial towing operations.

Floor sweepers & scrubbers

120Ah capacity provides sufficient runtime for continuous cleaning shifts, reducing downtime associated with frequent battery swaps.

Factory capability

VTCBATT Production and Service

VTCBATT not only focuses on customized design and excellent service to meet the diverse demands of different customers, but also devotes itself to precise and standardized manufacturing in every process to ensure the highest-quality batteries. Meanwhile, VTCBATT provides comprehensive support from pre-sales to after-sales, focusing on customer feedback to establish long-term and win-win cooperation. VTCBATT professional sales and technical engineer teams will be your custom battery experts for reliable and responsive project support.

▶

Modern Manufacturing

From raw materials mixing to cell testing, VTCBATT adopts automated manufacturing processes to improve production efficiency and battery quality, safety, and reliability. The manufacturing process is monitored and tested before material moves to the next procedure.

▶

Trusted by Global Customers

Over the past 20 years, VTCBATT has built partnerships with customers in more than 50 countries. Reliable quality, responsive service, and tailored battery solutions support long-term cooperation with equipment manufacturers, distributors, and brands.
