LiFePO4

Ultra long cycle life and lightweight Lifepo4 12V 200Ah battery for variable message boards, portable traffic signals, UPS for POS systems

Parameter	Specification
Nominal Voltage	12.8V
Capacity	200Ah
Energy	2560Wh
Discharge Cut-off Voltage	8V
Max Charge Current	100A
Max Discharge Current	200A(≤5s)
Cycle Life	>3000
Self-discharge Rate	2%
Dimensions	522 x 238 x 218/228mm
Weight	20Kg
Operating Temperature	-20℃ to 60℃
Storage Temperature	0 to 25ºC
Protection	Overcharge, Overdischarge, Overcurrent / Short-Circuit, Temperature, Cell Balancing

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotation View More Datasheet

Product overview

Ultra long cycle life and lightweight Lifepo4 12V 200Ah battery for variable message boards, portable traffic signals, UPS for POS systems | Battery Manufacturers in China & Battery Supply Factory

VTCBATT is a professional supplier of lightweight LiFePO4 12V 200Ah batteries with ultra long cycle life, designed for variable message boards, portable traffic signals and UPS for

01

LiFePO4 Battery Advantage

Ultra-Long Lifecycle: Over 3,000 deep cycles, lasting 10 times longer than traditional lead-acid batteries.
Lightweight: Typically uses the standard SLA case size, but 1/3 weight of the traditional 12V 200Ah lead-acid battery.Drop-in replacement for alarm system and UPS units.
Cost Per Cycle: Lifepo4 battery is only 1/4 cost of traditional lead acid battery in long run term.
100% Usable Capacity： Supports 100% DOD, delivering 40% more usable energy than equivalent lead-acid packs
Smart BMS Protection： Integrated Smart BMS prevents overcharging and shorts, ensuring absolute safety for users.
Eco-Friendly & Compliant ： Non-toxic, sustainable, and fully certified with CE, UN38.3, and RoHS standards.

Technical insight

Product and application details

Solar System

The 200Ah capacity provides extended energy storage for off-grid solar systems needing reliable daily power reserves.

Marine & Boating

Lightweight LiFePO4 construction reduces vessel weight while delivering stable 12V output for sensitive onboard electronics.

Motorcycles

Compact 12V form factor replaces heavy lead-acid units, offering superior vibration resistance for motorcycle electrical systems.

Variable message boards

Ultra long cycle life ensures consistent operation for variable message boards requiring frequent deep discharge cycles.

Trolling motors

High discharge capability supports sustained thrust demands of trolling motors without significant voltage drop during use.

Thrust motor

Lightweight design minimizes drag and weight impact on small boats while powering high-current thrust motors efficiently.

Portable traffic signals

Long cycle life ensures durability for portable traffic signals operating in remote locations with limited charging access.

Variable message boards

Ultra long cycle life ensures consistent operation for variable message boards requiring frequent deep discharge cycles.
