LiFePO4

Ultra long cycle life and lightweight Lifepo4 24V 20Ah battery for LED Light Panels, environmental monitoring, Point-of-Sale (POS) systems & kiosks

Parameter	Specification
Nominal Voltage	25.6V
Capacity	20Ah
Energy	512Wh
Discharge Cut-off Voltage	20V
Max Charge Current	20A
Max Discharge Current	70A(≤5s)
Cycle Life	>3000
Self-discharge Rate	2%
Dimensions	197 x 165 x 170/170mm
Weight	3.8Kg
Operating Temperature	-20℃ to 60℃
Storage Temperature	0 to 25ºC
Protection	Overcharge, Overdischarge, Overcurrent / Short-Circuit, Temperature, Cell Balancing

✓Certification supportCB, CE, UL, UN38.3, MSDS, IEC61000, IEC62133, EU2023/1542

Request a quotation View More Datasheet

Product overview

Ultra long cycle life and lightweight Lifepo4 24V 20Ah battery for LED Light Panels, environmental monitoring, Point-of-Sale (POS) systems & kiosks | Battery Manufacturers in China & Battery Supply Factory

VTCBATT is a professional supplier of lightweight LiFePO4 24V 20Ah batteries with ultra long cycle life, designed for LED light panels, environmental monitoring and POS systems & k

01

LiFePO4 Battery Advantage

Ultra-Long Lifecycle: Over 3,000 deep cycles, lasting 10 times longer than traditional lead-acid batteries.
Lightweight: Typically uses the standard SLA case size, but 1/3 weight of the traditional 24V 20Ah lead-acid battery.Drop-in replacement for alarm system and UPS units.
Cost Per Cycle: Lifepo4 battery is only 1/4 cost of traditional lead acid battery in long run term.
100% Usable Capacity： Supports 100% DOD, delivering 40% more usable energy than equivalent lead-acid packs
Smart BMS Protection： Integrated Smart BMS prevents overcharging and shorts, ensuring absolute safety for users.
Eco-Friendly & Compliant ： Non-toxic, sustainable, and fully certified with CE, UN38.3, and RoHS standards.

Technical insight

Product and application details

LED Light Panels

Its lightweight design reduces mounting load while 24V output directly drives high-efficiency LED arrays without conversion losses.

Security Camera

The ultra-long cycle life ensures years of operation for continuous recording, eliminating frequent maintenance visits for replacements.

environmental monitoring

LiFePO4 chemistry provides thermal stability for outdoor sensor nodes, ensuring consistent data transmission in varying ambient temperatures.

Point-of-Sale (POS) systems & kiosks

24V 20Ah capacity supports high-power touch screens and printers during brief power outages, keeping transactions secure.

solar-powered security cameras

Long cycle life withstands daily solar charging cycles, maintaining performance over years in remote, off-grid locations.

trail cameras

Lightweight construction minimizes impact on wildlife habitats while 24V supply powers motion sensors and infrared flashes reliably.

portable vacuum systems

24V voltage delivers the necessary torque for motorized suction, while compact size fits easily into handheld units.

electric fishing reels

High cycle life endures repeated high-current discharge during casting and reeling, extending the battery's usable lifespan significantly.
